ISOLATION TRANSFORMER TSE

FROM 45 TO 200 W

ISOLATION TRANSFORMER TSE

The TSE is an insulating transformer designed for airport lighting circuits supplied by a constant current regulator.

BENEFITS OF ISOLATION TRANSFORMER TSE

The TSE transformer is composed of a toroidal magnetical circuit on which primary and secondary windings are separately winded
in order to obtain very good electrical performances and a very good dielectric handling.

WATERTIGHT AND IMMERSIBLE
The whole is embedded in epoxy resin, which drives the transformer to be perfectly watertight and immersible.
EASY INSTALLATION
TSE transformers are stackable, primary circuits being directly put in series through their connector using plug devices.
The whole of the assembled device is presented on a support allowing a direct mounting on a HALFEN rail without any additional piece.
EASY MAINTENANCE
The absence of cables gives more room in the pits, so electrical circuits are easier to identify.

FEATURES OF ISOLATION TRANSFORMER TSE POWER RATINGS 45-65-100-150-200W PROTECTION INDEX IP 68 RATIO 6.6A / 6.6A ELECTRICAL CONFORMITY CEI 61823 DIELECTRIC primary 10 k V ca SIZE Lengh : 92 mm, Height : 184 mm Depth : 191 mm, WEIGHT 7 kg (approx)
